Cryogenic Liquid Oxygen/ Nitrogen/ Argon Storage Tank Manufacturer
Cryogenic Liquid Oxygen/ Nitrogen/ Argon Storage Tank Manufacturer
Main Parameter of Minwen cryogenic tanks:
- Capacity: 5m3 to 200m3
- Medium: LOX, LIN, LAr
- Insulation: Perlite vacuum insulation
- Design code: A2, C2, GC1, GB-150, ASME, U STAMP, ISO9001:2008
- Max. working pressure: ~35bar
- Main material: Stainless steel (inner vessel), carbon steel (outer shell)
- Type: Verical, horizontal cryogenic tanks
|
No. |
Model |
Capacity |
Max. working pressure |
Medium |
Outline Size (mm) |
Net Weight (KG) |
|
1 |
CFL-5/0.8 |
5m3 |
0.8MPa |
O2/LN2/Ar |
Φ1916*5262 |
3940 |
|
2 |
CFL-5/1.6 |
5m3 |
1.6MPa |
O2/LN2/Ar |
Φ1916*5262 |
4380 |
|
3 |
CFL-10/0.8 |
10m3 |
0.8MPa |
O2/LN2/Ar |
Φ2316*5981 |
5970 |
|
4 |
CFL-10/1.6 |
10m3 |
1.6MPa |
O2/LN2/Ar |
Φ2316*5981 |
6810 |
|
5 |
CFL-15/0.8 |
15m3 |
0.8MPa |
O2/LN2/Ar |
Φ2316*8035 |
8045 |
|
6 |
CFL-15/1.6 |
15m3 |
1.6MPa |
O2/LN2/Ar |
Φ2316*8035 |
9300 |
|
7 |
CFL-20/0.8 |
20m3 |
0.8MPa |
O2/LN2/Ar |
Φ2716*7377 |
9855 |
|
8 |
CFL-20/1.6 |
20m3 |
1.6MPa |
O2/LN2/Ar |
Φ2716*7377 |
11905 |
|
9 |
CFL-30/0.8 |
30m3 |
0.8MPa |
O2/LN2/Ar |
Φ2920*8904 |
14025 |
|
10 |
CFL-30/1.6 |
30m3 |
1.6MPa |
O2/LN2/Ar |
Φ2920*8904 |
16730 |
|
11 |
CFL-50/0.8 |
50m3 |
0.8MPa |
O2/LN2/Ar |
Φ3220*11204 |
21570 |
|
12 |
CFL-50/1.6 |
50m3 |
1.6MPa |
O2/LN2/Ar |
Φ3220*11204 |
25515 |
Minwen cryogenic liquid tanks have been widely used in various fields, including steel, petrochemical, medicine, electronics, textile, thermoelectricity, automobile, machinery manufacturing, aerospace and many other fields. Minwen will be dedicated to the general customer service, to save operating costs for users is our goal, customer satisfaction is our purpose.We will always uphold the "quality as life, service as the cornerstone" of the enterprise spirit, and strive to become a industry leader in cryogenic solutions.
