Cryogenic Liquid Carbon Dioxide (LCO2) Storage Tanks Manufacturer

Minwen cryogenic liquid CO2 storage tanks are used for a wide range of application. Our LCO2 tanks are customized to ensure smooth transportation and cost-efficient production. Cooling unit is optional for LCO2 tanks for better heat insulation.

Online Inquiry Email Us

Details

Cryogenic Liquid Carbon Dioxide (LCO2) Storage Tanks Manufacturer

Main Parameter of Minwen cryogenic LCO2 tanks.

- Capacity: 5m3 to 200m3

- Medium: LCO2 (liquid carbon dioxide)

- Insulation: Perlite vacuum insulation

- Design code: A2, C2, GC1, GB-150, ASME, U STAMP, ISO9001:2008

- Max. working pressure: 2.27MPa

- Main material: Carbon steel (inner vessel), carbon steel (outer shell)

- Type: Verical, horizontal liquid CO2 storage tanks

No.	Model	Capacity	Design pressure	Medium	Outline Size (mm)	Net Weight (KG)
1	CFL-5/2.16	5m3	2.2MPa	LCO2	Φ1916*5229	4785
2	CFL-10/2.16	10m3	2.2MPa	LCO2	Φ2316*5965	7520
3	CFL-15/2.16	15m3	2.2MPa	LCO2	Φ2416*7402	10015
4	CFL-20/2.16	20m3	2.2MPa	LCO2	Φ2616*7933	12905
5	CFL-30/2.16	30m3	2.2MPa	LCO2	Φ2920*8914	18170
6	CFL-50/2.16	50m3	2.2MPa	LCO2	Φ3120*11884	28240
7	CFL-60/2.16	60m3	2.2MPa	LCO2	Φ3324*12460	37170
8	CFL-100/2.16	100m3	2.2MPa	LCO2	Φ3528*16933	59315

Carbon dioxide (CO2) is a colorless, odorless and tasteless gas under normal conditions. CO2 exists in liquid form below the critical point temperature (31°C) and above the Triple point (-56.6°C and 5.18 bar (a) pressure). In order to store liquid CO2 for a long time, the cryogenic liquid CO2 storage tanks to be manufactured must be designed considering the critical point feature of the substance and a pressure of 22 bar or less and temperature values (-18°C) must be maintained. For this reason, it is very important to provide a strong thermal insulation of the liquid CO2 tanks to be produced.

Considering the needs of our customers, from the design of the LCO2 storage tanks to the commissioning, we strive to keep customer satisfaction at the highest level. Satisfying our customers who prefer us as Minwen Pressure Vessels family is our greatest reward.
